Compression Machine
 (85 vote(s))
|
|
|
|
|
Product code:
CO-325.4
In stock:
yes
|
|
| CO-325.4
| Alternative model of compression machine :
CO-XXX.X-D As specified above, with digital read out |
ASTM C-39
For determining compressive strength of concrete cube 15 x 15 x15 cm or concrete cylinder 15 cm dia. x 30 cn height |
| Frame | Heavy-duty welded steel construction 30 cm
(profile steel columns 10 thick botttom and upper plate) |
Hydraulic System
For 1500 kN Cap. |
Cast iron cylinder,
Hard-chromed piston, 230 mm diameter
Maximum working pressure 50.000 kPa
Overall dimension 280 mm dia. x 320 mm height
Single action, gravity return |
Hydraulic System
For 2000 kN Cap. |
Cast iron cylinder,
Hard-chromed piston, 230 mm diameter
Maximum working pressure 50.000 kPa
Overall dimension 300 mm dia. x 320 mm height
Single action, gravity return |
Hydraulic System
For 3000 kN Cap. |
Cast iron cylinder,
Hard-chromed piston, 250 mm diameter
Maximum working pressure 50.000 kPa
Overall dimension 330 mm dia. x 320 mm height
Single action, gravity return |
| Hydraulic Pump |
Electric, 220 V AC, 50-60 HZ, 1000 Watt, 1 Phase
Single action, variable speed
6.000 ml reservoir capacity
Maximum working pressure 50.000 kPa
Single action, gravity return |
| Force Gauge |
Bourdon tube manometer, 280 mm dial diameter
With maximum load pointer. Steel box housing.
Calibrated by JNK |
Compressive
Platen |
Upper : 180 x 180 mm, ball seating
Lower : 250 mm diameter |
| Clearance |
Horizontal: 290 mm
Vertikal : 310 mm |
| Dimension |
760 x 320 x 1400 mm (l x w x h) approx. |
| Weight |
500 kg |
| CO-325.3 | Compression Machine | 1500 kN capacity,
10 kN increments |
|---|
| CO-325.4 | Compression Machine | 2000 kN capacity,
10 kN increments |
|---|
| CO-325.5 | Compression Machine | 3000 kN capacity,
20 kN increments |
|---|
|
|
|
|
